DORMAKABA – RCI 4 SERIES CENTERLINE ELECTRIC STRIKES

Contact for Pricing

The RCI 4 Series accommodates most door frame types and materials.

Categories: ,

Description

Features:

  • Accommodates 3/4″ (19mm) latch projection
  • 1-1/2″ (38mm) cut-out depth accommodates most door frame material types
  • Use with wide range of door thicknesses, 1-3/8″ to 2-3/8″ (35mm-60mm)
  • Standard mounting tabs and fasteners included
  • Non-handed
  • Trim plate included to cover up irregular frame cutout
  • 200mA 11-16VAC, 12VAC/VDC, 24VAC/VDC (At 12VDC)
  • 1,500lbf Static2 70ft-lb Dynamic (1,500lbf Static for fire-rated models, 1,000lbf for non-fire-rated 04 & 14 faceplates, 500lbf for 05, 07, 08 & 19 faceplates.)
  • 500,000 Cycles (Fire-rated (F) models only, 250,000 for other models)
  • Fail-Secure & Fail-Safe
  • Optional 1-1/2-Hour Models Available (Fire-rated (F) models only available in fail-secure mode with 04 & 14 faceplates)
  • UL 1034 burglary-resistant Listed
  • UL 10C, 1-1/2-hour fire-rating Listed
  • CAN/ULC S104, 1-1/2-hour fire-rating Listed
  • Certified to ANSI/BHMA standard A156.31, Grade 1
  • 3 Year Limited Warranty
