YALE ASSURE LOCK INTERCONNECTED LOCKSET

Description

Yale Assure Lock Interconnected combines electronic deadbolts with the convenience of a passage lever for panic proof egress. From the inside, both the latch bolt and the deadbolt are retracted simultaneously in a single motion for a quick and easy exit. Available in standalone, Bluetooth, Z-Wave or Zigbee configurations. Choose from 12 lever styles.

These locks present a significant benefit to multi-family and multi-unit projects, commonly requiring rekeying (multi-family residences, assisted living facilities, public restrooms, offices & small businesses).

• YRC216: Keyed deadbolt with push button keypad. Single point lock
• YRC226/YRC620: Keyed deadbolt with touchscreen keypad. Single point lock
• YRC256: Key free deadbolt with touchscreen keypad. Single point lock
• Keying KD (Keyed Different) standard, master keying available to order
• Stores 25 pin codes standalone or 250 when integrated into a Z-Wave or ZigBee system
• Voice assisted programming on the touchscreen models
• Solid metal escutcheon
• Door specs: 2-1/8″ face bore, 1″ edge bore, 4″ or 5-1/2″ center to center (specify)
• Backset 2-3/8″ or 2-3/4″
• Door thickness: 1-3/8″ to 1-3/4″
• Field adjustable handing
• Cylinder KW-1 compatible standard, other cylinders/keyways available to order
• Round Corner standard, Other strikes available to order.
• Strike lever: 2-1/4″ full lip
• Deadbolt strike: 1″ x 2-1/4″
