VON DUPRIN – PS914 POWER SUPPLY

Description

The Von Duprin PS914 is a 4-amp power supply designed to manage high in-rush requirements.

Features:

• 4-amp, Class 2, filtered and regulated power
• Clean, consistent power output helps protect the sensitive circuitry of downstream products
• Overload protection prevents too much current being pulled by an overload of devices
• 12/24 VDC output field selectable with plug-in jumper
• Externally visible LED indicator provides visual status on AC input
• Ability to provide continual power with battery backup
• Universal 120-240 VAC, fused primary input
• Externally visible AC input indicator with isolated SPDT contacts
• Battery back-up board auto-selects voltage
• LED indicator provides visual status on DC output
• Cabinet accommodates 1 or 2 batteries, up to 2 option boards, plus fire alarm relay and battery backup board
• Switching supply, 5% regulation, 360Vpp max ripple
• Operating temperature: 32° to 120° F (0° to 49°C)
• 14″H x 12″W x 4″D in grey, baked enamel finish
• Hinged cover with lockdown screws and optional key lock
• UL294 listed for access control
• ULC-S318
• RoHS
• 5 year limited warranty
